Tractor · 1998Unverified

Challenger 95E

Name: Challenger 95E
Brand: Challenger

Challenger 95E — Agricultural Crawler tractor · 306 hp. Reference specifications; pending source verification.

The Challenger 95E is a tractor model with a rated power output of 306 hp, placing it at the high end of its class. It was manufactured from 1998 to 2001. The model features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, coupled with a tracked undercarriage and hydrostatic transmission. Its listed operating weight is 16111 kg, and it is suitable for operations covering areas of 1,500 acres or more.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

306 hp

Max power

254.9 kW

Weight

16111 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

306 hp

Recorded weight

16111 kg

Transmissions

10-speed full power shift

Production years

1998-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerChallenger (a part of Caterpillar)Reference

Agricultural Crawler tractorReference

Original price$238,000Reference

DrivecrawlerReference

Steeringhydrostatic differential steeringReference

Hydraulic caliper disc brakesReference

Cab standardReference

Engine

Caterpillar 11.9L 6-cyl dieselReference

Fuel tank1059.8 LReference

Engine305.7 kWReference

Drawbar (tested)244.4 kWReference

CaterpillarReference

turbocharged intercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement11.9 LReference

Bore/Stroke130 x 150 mmReference

Power305.7 kWReference

Air cleanerdual paper elements with aspiratorReference

Compression16:1Reference

Rated RPM2100Reference

Starter volts12Reference

Coolant capacity75.7 LReference

Max power254.9 kWReference

Power at rated engine speed228.1 kWReference

Max power244.4 kWReference

Transmission

10-speed full power shiftReference

Typefull power shiftReference

Gears10 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)225.2 kWReference

PTO (tested)254.9 kWReference

Typeclosed centerReference

Valves4Reference

Total flow151.4 lpmReference

Rear PTO Type1000Reference

Power at rated PTO speed228.4 kWReference

Dimensions

Wheelbase271 cmReference

Weight16111 kgReference

25-inch tracksReference

Operating weight16111 kgReference

Challenger 95E Tracks

Width63 cmReference

Test results

Diesel 10-speed crawlerMay 19 - June 2, 1998Link: OCED Tractor Test 1751 fileReference

PTO performanceReference

Fuel use63.6 l/hourReference

Fuel use60.9 l/hourReference

Fuel use60.2 l/hourReference

Drawbar performanceReference

Fuel use72.7 l/hourReference

Gear 5 used for power test.Reference

Max pull15967 kgReference

Gear 1 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
