Tractor · 2007Unverified
Claas Arion 630
Claas Arion 630 — Model year 2007-20112012-20172017-2025 · 146 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
146 hp
Weight
6218 kg
Hover a source tag to verify
Overview
ManufacturerClaasReference
Row-Crop tractorReference
Four-wheel driveReference
Power steeringReference
Trailer brakespneumaticReference
Cab standard with air-conditioning.Reference
Variants
Arion 630deluxe modelReference
Arion 630Ceconomy modelReference
Engine
John Deere 6.8L 6-cyl dieselReference
Fuel tank330.1 LReference
Engine108.5 kWReference
John DeereReference
turbocharged intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement6.8 LReference
EmissionsTier 3Reference
Power108.5 kWReference
Rated RPM2200Reference
Torque630.1 NmReference
Torque RPM1650Reference
Starter typeelectricReference
Oil change500 hReference
Transmission
24-speed partial power shift with power shuttleReference
TransmissionHexashiftReference
Typepartial power shift with power shuttleReference
Gears24 forward and reverseReference
PTO & Hydraulics
Typeload sensingReference
Pressure200.0 barReference
Valves2 to 6Reference
Total flow110.1 lpmReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540E/1000/1000EReference
Dimensions
Wheelbase281 cmReference
Weight6218 kgReference
Front tire16.9R28Reference
Rear tire20.8R38Reference
Ag front16.9R28Reference
Ag rear20.8R38Reference
Length515 cmReference
Height (cab)300 cmReference
Ground clearance50 cmReference
Operating6218 kgReference
Ballasted8397 kgReference
Capacities
Max capacity9248 kgReference
Max capacity10999 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
