Cockshutt 40
Cockshutt 40 — Row-Crop tractor · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Max power
28.2 kW
Weight
2406 kg
Hover a source tag to verify
Overview
ManufacturerCockshuttReference
Row-Crop tractorReference
Built in Brantford, Ontario, CanadaReference
Original price was $3,600 in 1957Reference
The Cockshutt model 40 was available with a Buda 230 cubic inch engine, with choice of gasoline, diesel, LP-gas, or distillate as the fuel. In 1955, a Perkins diesel was also an option, sold as the Cockshutt 40PD and labeled the 40D4 Golden Eagle in the United States.Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Variants
40Buda engineReference
40D4Perkins engineReference
Engine
Buda 3.8L 6-cyl gasolineReference
Buda 3.8L 6-cyl dieselReference
Drawbar (tested)28.2 kWReference
Belt (tested)32.3 kWReference
Buda 6B230Reference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke87 x 105 mmReference
Air cleaneroil bathReference
Compression6.2:1Reference
Rated RPM1650Reference
Starter volts6Reference
Buda 6BD230Reference
dieselReference
Belt power (max)32.3 kWReference
Max power28.2 kWReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)32.1 kWReference
Rear PTO Type540Reference
Dimensions
Wheelbase220 cmReference
Weight2406 kgReference
Operating weight2406 kgReference
Ballasted weight3797 kgReference
Front tread135/149 cmReference
Rear tread156 to 200 cmReference
40 Serial Number Location
Left side on main frame.Reference
40 Serial Numbers
1949101Reference
1950194Reference
19514098Reference
19526896Reference
195310472Reference
195411363Reference
195520001Reference
195630001Reference
195740001Reference
195850001Reference
Final50372Reference
FAQ: How to read a serial number table.Reference
Test results
Gasoline 6-speed 2WDJune 12 - 17, 1950Link: Nebraska Tractor Test 442 fileReference
Belt fuel use (max)17.0 l/hourReference
Drawbar performanceReference
Gear 4 used for power test.Reference
Max pull2512 kgReference
Gear 1 used for pull test.Reference
