Tractor · 1961Unverified
Farmall 404
Farmall 404 — Row-Crop tractor · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Max power
24.6 kW
Weight
3400 to 4115 pounds
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Row-Crop tractorReference
Built in Louisville, Kentucky, USAReference
Total built2440Reference
Two-wheel driveReference
SteeringmanualReference
Steeringpower (optional)Reference
Differential mechanical disc brakesReference
Open operator station. Optional deluxe deep-cushion seat with padded backrest.Reference
Variants
Farmall 404row-crop chassisReference
IH 404utility chassisReference
2404industrialReference
Engine
International Harvester 2.2L 4-cyl gasolineReference
International Harvester 2.2L 4-cyl LP-gasReference
Drawbar (claimed)24.9 kWReference
Drawbar (claimed)21.6 kWReference
Plows2-3Reference
Drawbar (tested)24.6 kWReference
International Harvester C-135Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke83 x 103 mmReference
Air cleaneroil bathReference
Compression7.7:1Reference
Rated RPM2000Reference
Idle RPM900-2000Reference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity14.2 LReference
LP-gasReference
Compression8:1Reference
Power at rated engine speed27.4 kWReference
Max power24.6 kWReference
Transmission
4-speed gearReference
8-speedReference
4-speed manual shuttleReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutch9-inch dry discReference
Oil capacity18.9 LReference
TransmissionDual-RangeReference
Gears8 forward and 2 reverseReference
Add high range to basic four-speed transmission.Reference
Typemanual shuttleReference
Gears4 forward and reverseReference
PTO & Hydraulics
PTO (claimed)27.4 kWReference
PTO (claimed)24.6 kWReference
PTO (tested)27.4 kWReference
Hydraulic system18.9 LReference
TypeliveReference
Capacity18.9 LReference
Valves1 or 2Reference
Total flow17.0 lpmReference
Total flow35.2 lpmReference
Rear TypeIReference
Rear PTOtransmissionReference
Rear PTO Type540Reference
Capacities
Fuel61.3 LReference
Fuel71.9 LReference
Diameter27 cmReference
RPM948Reference
Speed832.10 meters/minReference
Dimensions
Wheelbase208 cmReference
Wheelbase223 cmReference
Weight3400 to 4115 poundsReference
Front tire5.00-15Reference
Rear tire11.2-36Reference
Ag front5.00-15Reference
Ag rear11.2-36Reference
Ag rear12.4-36Reference
Length238 cmReference
Height (steering wheel)162 cmReference
Front tread20 cmReference
Front tread127 to 208 cmReference
Rear tread121 to 203 cmReference
Rear tread121 to 223 cmReference
Shipping1542 kgReference
Operating1866 kgReference
Ballasted3014 kgReference
Farmall 404 attachments
front-end loaderReference
404 Serial Number Location
Serial number plate on the left side of the tractor's clutch housing.Reference
404 Serial Numbers
1961501Reference
1962826Reference
19631936Reference
19642259Reference
19652568Reference
19662790Reference
19672980Reference
19683170Reference
FAQ: How to read a serial number table.Reference
Attachment overview
International Harvester 2001 loaderReference
Matched equipment for the Farmall 404 included the 209A two-bottom or 309A three-bottom plows, and the model 200 rear-mounted cultivator.Reference
Test results
Gasoline 8-speed 2WDMay 21 - June 4, 1962Link: Nebraska Tractor Test 818 fileReference
PTO performanceReference
Fuel use11.4 l/hourReference
Drawbar performanceReference
Gear 3-Low used for power test.Reference
Max pull2267 kgReference
Gear 1-Low used for pull test.Reference
Speeds
With 11.2-36 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
