Tractor · 1951Unverified
Farmall Super FC
Farmall Super FC · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Built in Saint Dizier, FranceReference
The Farmall Super FC is the French-built version of the Farmall Super C. A diesel engine, not available in the US-built version, was added to meet the needs of European farmers.Reference
Two-wheel driveReference
SteeringmanualReference
Differential mechanical contracting band brakesReference
Open operator station.Reference
Variants
Super FC-CgasolineReference
Super FC-DdieselReference
Super FC-Etractor-fuelReference
Engine
International Harvester 2.0L 4-cyl gasolineReference
International Harvester 2.0L 4-cyl dieselReference
distillateReference
Fuel tank41.6 LReference
Engine19.1 kWReference
International Harvester C-123Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke79 x 102 mmReference
Coolant capacity12.3 LReference
SparkplugChamption 15-AReference
SparkplugAC-85SReference
Sparkplug gap0.635 mmReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.356 mmReference
Oil capacity4.7 LReference
International Harvester FD-123Reference
dieselReference
Power19.1 kWReference
Rated RPM1650Reference
Transmission
4-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears4 forward and 1 reverseReference
Clutch9-inch dry discReference
Oil capacity18.9 LReference
Oil typeSAE 90Reference
PTO & Hydraulics
TypeIH Touch ControlReference
Rear PTO Type540Reference
Dimensions
Wheelbase232 cmReference
Front tire4.00x15Reference
Rear tire9.00x36Reference
Ag front4.00x15Reference
Ag rear9.00x36Reference
Length328 cmReference
Width198 cmReference
Height (steering wheel)184 cmReference
Height (exhaust)211 cmReference
Clearance (rear axle)57 cmReference
Front tread150 to 211 cmReference
Rear tread121 to 175 cmReference
Rear tread142 to 198 cmReference
Capacities
Diameter21 cmReference
Width15 cmReference
RPM1363Reference
Speed924.46 meters/minReference
Speeds
With 9x36 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
