The Ford 3415 is a tractor with a rated power of 38 hp, positioning it at the lighter end of its class. It was manufactured from 1993 to 1995. Equipped with a 4-cylinder diesel liquid-cooled engine, the tractor is paired with two-wheel drive and a 12-speed gearbox. Its operating weight is listed at 1859 kg, with a capacity for operations of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Weight
1859 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
38 hp
Recorded weight
1859 kg
Transmissions
12-speed
Production years
1993-1995
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerShibauraReference
Compact Utility tractorReference
Built in JapanReference
Original price was $17,900 in 2000Reference
Two-wheel driveReference
Two-post ROPS.Reference
Engine
Shibaura 2.2L 4-cyl dieselReference
Fuel tank42.0 LReference
Engine32.8 kWReference
ShibauraReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke84 x 100 mmReference
Power32.8 kWReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)28.3 kWReference
Typeopen centerReference
Pump flow24.6 lpmReference
Rear TypeIReference
Rear lift1573 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Wheelbase189 cmReference
Weight1859 kgReference
Front tire6.00-16Reference
Rear tire13.6-28Reference
Ag front6.00-16Reference
Ag rear13.6-28Reference
3415 Serial Numbers
Location:left side of transmissionReference
1993UX20001Reference
1994UX20798Reference
1995UX21715Reference
1996UX22323Reference
1997UX22504Reference
1998UX22858Reference
1999UX23290Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
