Tractor · 1963Unverified
International Harvester 806
International Harvester 806 — Standard-tread tractor · 95 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
95 hp
Weight
8460 to 9220 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Standard-tread tractorReference
Total built8,052Reference
Original price$6,800 (1967)Reference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Hydraulic dry disc brakesReference
Open operator stationReference
Variants
IH 806standard-treadReference
Farmall 806row-cropReference
Engine
International Harvester 5.9L 6-cyl dieselReference
Interntional Harvester 4.9L 6-cyl gasolineReference
International Harvester 4.9L 6-cyl LP gasReference
Drawbar (claimed)64.6 kWReference
International Harvester D-361Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke105 x 114 mmReference
Air cleanerdual dryReference
Rated RPM2400Reference
Idle RPM900-2400Reference
Starter volts12Reference
Coolant capacity22.7 LReference
Interntional Harvester C301Reference
gasolineReference
Displacement4.9 LReference
Bore/Stroke97 x 112 mmReference
Compression7.7:1Reference
International HarvesterReference
LP gasReference
Compression8.71:1Reference
Transmission
8-speed unsynchronizedReference
16-speed partial power shiftReference
TypeunsynchronizedReference
Gears8 forward and 4 reverseReference
Four gears (1-4) in low, high, and reverse ranges.Reference
TransmissionTorque AmplifierReference
Typepartial power shiftReference
Gears16 forward and 8 reverseReference
As two-range Torque Amplifer (TA) to the basic transmission. Pulling back on the left-hand TA lever provides a clutchless shift to a lower speed for each gear. Pushing the lever forward return to direct-drive mode.Reference
PTO & Hydraulics
PTO (claimed)70.8 kWReference
Hydraulic system64.3 LReference
Typeopen centerReference
Capacity64.3 LReference
Pump flow45.4 lpmReference
Pump flow11.4 lpmReference
Total flow90.8 lpmReference
Steering flow34.1 lpmReference
Rear TypeIIReference
TypeIH Fast HitchReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Rear PTO Type540/1000Reference
Capacities
Fuel159.0 LReference
Fuel181.7 LReference
Dimensions
Wheelbase231 cmReference
Weight8460 to 9220 poundsReference
Front tire7.50-20Reference
Rear tire18.4-34Reference
Ag front7.50-20Reference
Ag rear18.4-34Reference
Ag rear23.1-34Reference
Length388 cmReference
Width269 cmReference
Height (steering wheel)208 cmReference
Shipping weight3837 kgReference
Shipping weight4182 kgReference
Bar rear axle82 mmReference
Front tread134 cmReference
Front tread142/175/203 cmReference
Rear tread152 to 213 cmReference
806 Serial Numbers
1963501Reference
19641403Reference
19653758Reference
19665917Reference
19677409Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Charging amps25Reference
Batteries2 (diesel)Reference
Batteries1 (gas/LP)Reference
Battery volts6 (diesel)Reference
Battery volts12 (gas/LP)Reference
Battery AH170 (diesel)Reference
Battery AH60 (gas/LP)Reference
Speeds
With 16.9-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
