J.I. Case 1470 Traction King
J.I. Case 1470 Traction King — Four-wheel Drive (4WD) tractor · 145 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
145 hp
Max power
94.6 kW
Weight
7847 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Four-wheel Drive (4WD) tractorReference
Original price was $19,000 in 1972Reference
Drive4x4 4WDReference
Steeringfour-wheel hydraulic power steeringReference
Hydraulic disc brakesReference
Open operator station. Cab optional.Reference
Engine
J.I. Case 8.3L 6-cyl dieselReference
Fuel tank264.9 LReference
Drawbar (claimed)94.0 kWReference
Drawbar (tested)94.6 kWReference
J.I. CaseReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke117 x 127 mmReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM2000Reference
Starter volts24Reference
Power at rated engine speed108.0 kWReference
Max power94.6 kWReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)108.1 kWReference
PTO (tested)108.0 kWReference
Typeopen centerReference
Pump flow58.7 lpmReference
Rear TypeIIIReference
Rear PTO Type1000Reference
Engine RPM1000@2000Reference
Dimensions
Wheelbase259 cmReference
Weight7847 kgReference
Front tire28.1-26Reference
Rear tire28.1-26Reference
Ag front28.1-26Reference
Ag rear28.1-26Reference
Ag front18.4x30Reference
Ag rear18.4x30Reference
Operating weight7847 kgReference
Test results
Diesel 8-speed 4WDApril 15 - 23, 1969Link: Nebraska Tractor Test 1006 fileReference
PTO performanceReference
Fuel use31.0 l/hourReference
Drawbar performanceReference
Fuel use30.3 l/hourReference
Gear 4 used for power test.Reference
Max pull8047 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
