Tractor · 1978Unverified
John Deere 3030
John Deere 3030 — Row-Crop tractor · 94 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
94 hp
Weight
7297 to 8069 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Row-Crop tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS. Cab available.Reference
Variants
3030LS12-speedReference
Engine
John Deere 5.4L 6-cyl dieselReference
Engine (gross)69.9 kWReference
Engine (net)63.0 kWReference
John DeereReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.4 LReference
Bore/Stroke102 x 110 mmReference
Power (net)63.0 kWReference
Power (gross)69.9 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression16.8:1Reference
Rated RPM2500Reference
Idle RPM750-2660Reference
Operating RPM1200-2500Reference
Torque285.0 NmReference
Torque RPM1200Reference
Starter volts12Reference
Oil capacity11.5 LReference
Coolant capacity19.0 LReference
Transmission
12-speedReference
TransmissionHi-LoReference
Gears12 forward and 6 reverseReference
Clutchdry discReference
Oil capacity57.0 LReference
PTO & Hydraulics
PTO (claimed)57.0 kWReference
Hydraulic system56.8 LReference
Typeclosed centerReference
Capacity56.8 LReference
Pressure155.0 barReference
Pump flow46.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift3380 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2170Reference
Engine RPM1000@2170Reference
Capacities
Fuel106.0 LReference
Max capacity6000 kgReference
Dimensions
Wheelbase246 cmReference
Weight7297 to 8069 poundsReference
Front tire7.50-20Reference
2WD Rear tire16.9-38Reference
2WD Standard tires (ag)Front: 7.50-20. Rear: 16.9-38Reference
4WD Standard tires (ag)Front: 11.2-24. Rear: 16.9-38Reference
Length400 cmReference
Width203 cmReference
Height (ROPS)268 cmReference
Height (cab)273 cmReference
3660 kgReference
Shipping3309 kgReference
3030 Serial Numbers
Location:Serial number plate on the right side of the Deere 3030 tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps28Reference
Batteries2Reference
Battery volts12Reference
Battery AH55Reference
Speeds
With 16.9-38 rear tires and 25KPH transmission option.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
