Tractor · 2019Unverified

John Deere 3043D

John Deere 3043D — 3D Series · 42 hp. Reference specifications; pending source verification.

The John Deere 3043D is a tractor with a rated output of 42 hp, categorising it among the more compact options in its class. It was manufactured in 2019. The tractor features a 3-cylinder turbocharged diesel liquid-cooled engine, which transmits power through four-wheel drive via an 8-speed gearbox. It has a listed weight of 1288 kg and is designed for use on areas of approximately 200 ac.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
42 hp
Max power
41.6 hp (2,800 rpm)
Weight
1288 kg

Catalogue coverage

Variants represented
2
Richest spec table
120 rows
Recorded power
42 hp
Recorded weight
1288 kg
Transmissions
8-speed mechanical shuttle
Production years
2019-2019
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference
Compact Utility tractorReference
Built in IndiaReference
Original price was $23,721 in 2019Reference
Four-wheel driveReference
Final drivesspur gearReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post folding ROPS.Reference

Engine

Yanmar 1.6L 3-cyl dieselReference
Fuel tank36.7 LReference
Engine (gross)31.0 kWReference
Yanmar 3TNV86CT-KJPTReference
turbocharged dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.6 LReference
Bore/Stroke86 x 90 mmReference
EmissionsTier 4Reference
Power (gross)31.0 kWReference
Fuel systemhigh pressure common rail direct injectionReference
Air cleanerdual dry elementReference
Compression19.1:1Reference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Starter power1.4 kWReference
Oil capacity4.5 LReference
Oil change400 hReference
Coolant capacity5.5 LReference
Fuel TypeDieselReference
No of CylindersThreeReference
Rated engine speed2,800 rpmReference
Emissions complianceFinal Tier 4Reference
Cylinder linersCast-in-blockReference
Engine torque at rated speed105.7 NmReference
Injection pump typeHigh pressure common rail direct injectionReference
AspirationTurbochargedReference
Bore and stroke86 x 90 mmReference
Compression ratio19.1:1Reference
Cooling systemLiquidReference

Transmission

8-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Oil capacity32.9 LReference
Four gears in two ranges with left-hand shuttle. Tractor must be stopped, and clutch used, to shift gear, range, or shuttle.Reference
Transmission TypeSync ShuttleReference
Wheel Drive4WDReference
Gear Shift LocationRight-hand sideReference

PTO & Hydraulics

PTO (claimed)27.1 kWReference
Typeopen centerReference
Pressure172.4 barReference
Rear valves2Reference
Pump flow19.3 lpmReference
Total flow39.0 lpmReference
Steering flow16.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)757 kgReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2400Reference

Dimensions

Wheelbase157 cmReference
Weight1288 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 7-14. Rear: 11.2-24Reference
Lawn/turf front27x8.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front25x8.5-14Reference
Industrial rear15-19.5Reference
Length282 cmReference
Width145 cmReference
Height (steering wheel)150 cmReference
Clearance (front axle)35 cmReference
Clearance (rear axle)33 cmReference
Front tread105 cmReference
Rear tread109 cmReference
Shipping1288 kgReference
Max front axle879 kgReference
Max rear axle1599 kgReference

John Deere 3043D attachments

front-end loaderReference

3043D Serial Numbers

Location:Serial number plate on the left side of the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery CCA600Reference
Battery volts12Reference
Battery size600 CCAReference
Alternator size55 ampReference

Capacities

Max capacity2100 kgReference
Front Axle capacity880 kgReference
Rear Axle capacity1,599.8 kgReference
Crankcase oil volume4.5 LReference

Speeds

With 15x19.5 rear tires. Reverse speeds are 5% faster than forward.Reference

General

Make & ModelYanmar® @ 3TNV86CT-KJPTReference
LubricationPressurizedReference
Cruise controlfalseReference
Differential lockYesReference
Rollover protective structureType\\nFoldable\\nASABE S478Reference
PlatformStraddleReference

Power

Max Power41.6 hp (2,800 rpm)Reference

PTO

PTO Power36.3 hpReference
Rear PTO PowerAvailableReference
Rear PTO ControlMechanicalReference
Rear PTO RPM540 rpmReference

Steering & brakes

BrakesWet diskReference
Steering typePower steeringReference

Hydraulics

Pump Rated Output (total)39.2 l/minReference
Hydraulics TypeSingle gearReference
Maximum operating pressure2,495 psiReference
Remote ValvestwoReference
Steering & Implements flow16.8 L/min (22.4 L/min)Reference
Rear Hitch category (SAE designation)3-Point | Category 1Reference

Dimensions & weight

Ground ClearanceMinimum: 331 mmReference
Turning radius1.6 mReference
Overall weight1,288.2 kgReference

Wheels & tyres

Front Wheel TypeR1 Bar: 7-14\\nR3 Turf: 27x8.5-15\\nR4 Industrial: 25x8.5-14Reference

Operator station

Cab AvailabilityfalseReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
