Tractor · 1992Unverified
John Deere 6300L
John Deere 6300L — Orchard/Vineyard tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
7497 to 8004 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two- or four-wheel driveReference
Power steeringReference
Differential hydraulic wet disc brakesReference
ROPS. Cab optional.Reference
Variants
6300utility tractorReference
6300Llow-profileReference
Engine
John Deere 3.9L 4-cyl dieselReference
Engine69.4 kWReference
John Deere 4039Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke106 x 110 mmReference
Power69.4 kWReference
Compression17.8:1Reference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Starter power3.1 kWReference
Oil capacity12.0 LReference
Coolant capacity11.0 LReference
Transmission
12-speed fully synchronizedReference
21-speedReference
16-speed partial power shiftReference
28-speed partial power shiftReference
TransmissionJohn Deere SyncroPlusReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Oil capacity51.9 LReference
Three gears, plus reverse, in four ranges.Reference
TransmissionJohn Deere SyncroPlus CreeperReference
Gears21 forward and 7 reverseReference
TransmissionJohn Deere PowrQuadReference
Typepartial power shiftReference
Gears16 forward and reverseReference
Oil capacity48.8 LReference
Four power shift gears in four synchronized ranges, with reverser.Reference
TransmissionJohn Deere PowrQuad CreeperReference
Gears28 forward and reverseReference
PTO & Hydraulics
PTO (claimed)55.9 kWReference
Typeclosed center pressure flow compensatedReference
Pressure200.0 barReference
Valves2Reference
Total flow68.1 lpmReference
Total flow96.1 lpmReference
Rear TypeIIReference
Rear lift2222 kgReference
Rear PTO Type540Reference
Rear PTO Type540/1000 (optional)Reference
Capacities
Fuel113.6 LReference
Front axle6.4 LReference
Front hubs3.4 LReference
Dimensions
Wheelbase240 cmReference
Weight7497 to 8004 poundsReference
Front tire27/9.5-15Reference
Rear tire16.9-24Reference
Ag front27/9.5-15 (2WD)Reference
Ag front10.5/80-18 (4WD)Reference
Ag rear16.9-24Reference
Length414 cmReference
Width197 cmReference
Height (steering wheel)169 cmReference
Height (ROPS)229 cmReference
Height (Folded ROPS)169 cmReference
Shipping weight3400 kgReference
Shipping weight3630 kgReference
Ground clearance32 cmReference
John Deere 6300L attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery CCA780Reference
Battery volts12Reference
Battery AH110Reference
Battery AH154Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
