Tractor · 1997Unverified
John Deere 8200T
John Deere 8200T — Agricultural Crawler tractor · 182 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
182 hp
Max power
150.4 kW
Weight
23650 to 24430 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Agricultural Crawler tractorReference
Built in Waterloo, Iowa, USAReference
DrivecrawlerReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
CommandView Cab standardReference
Variants
8200wheeled tractorReference
8200Tcrawler tractorReference
Engine
John Deere 8.1L 6-cylReference
Drawbar (tested)115.6 kWReference
John DeereReference
turbocharged intercooledReference
6-cylinderReference
liquid-cooledReference
Displacement8.1 LReference
Bore/Stroke116 x 129 mmReference
Air cleanertwo paper elementsReference
Compression16.5:1Reference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity21.5 LReference
Coolant capacity34.0 LReference
Max power150.4 kWReference
Power at rated engine speed135.7 kWReference
Max power115.6 kWReference
Transmission
16-speed full powershiftReference
Typefull powershiftReference
Gears16 forward and 4 reverseReference
Oil capacity246.1 LReference
PTO & Hydraulics
PTO (claimed)134.2 kWReference
PTO (tested)150.4 kWReference
Hydraulic system246.0 LReference
Typepressure/flow compensated (PFC)Reference
Capacity246.0 LReference
Pressure200.0 barReference
Valves3 to 5Reference
Pump flow113.6 lpmReference
Pump flow143.8 lpmReference
Rear TypeIII/IIINReference
Rear lift7098 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Capacities
Fuel492.1 LReference
Dimensions
Wheelbase226 cmReference
Weight23650 to 24430 poundsReference
16-inch tracksReference
Length525 cmReference
Length557 cmReference
Width263 cmReference
Height (cab)312 cmReference
Ground clearance44 cmReference
Ground clearance55 cmReference
Shipping10727 kgReference
Operating11081 kgReference
Ballasted11607 kgReference
8200T Serial Numbers
Location:Rear of tractorReference
1997901001Reference
1998902001Reference
1999904001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps140Reference
Batteries2Reference
Battery volts12Reference
John Deere 8200T Tracks
Width40 cmReference
Width60 cmReference
Width76 cmReference
Test results
Diesel 16-speed crawlerApril 10 - May 1, 1998Link: OCED Tractor Test 1745 fileReference
PTO performanceReference
Fuel use41.3 l/hourReference
Fuel use40.1 l/hourReference
Drawbar performanceReference
Fuel use39.7 l/hourReference
Gear 9 used for power test.Reference
Max pull11154 kgReference
Gear 3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
