Tractor · 1998Unverified
Massey Ferguson 5150
Massey Ferguson 5150 — Four-wheel Drive (4WD) tractor · 250 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
250 hp
Weight
10800 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Four-wheel Drive (4WD) tractorReference
Built in Granadero Baigorria, Santa Fe, ArgentinaReference
Four-wheel driveReference
Articulated power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 8.3L 6-cyl dieselReference
Fuel tank604.8 LReference
Engine186.4 kWReference
Cummins 6CT8.3Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
Power186.4 kWReference
Rated RPM2200Reference
Torque980.4 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts24Reference
Oil capacity24.0 LReference
Coolant capacity12.3 LReference
PTO & Hydraulics
Pressure156.9 barReference
Valves4Reference
Pump flow160.1 lpmReference
Steering flow36.0 lpmReference
Rear TypeIIIReference
Dimensions
Wheelbase314 cmReference
Weight10800 kgReference
Front tire18-4x38Reference
Rear tire18-4x38Reference
Ag front18-4x38Reference
Ag front24.5x32Reference
Ag rear18-4x38Reference
Ag rear24.5-32Reference
Length690 cmReference
Width329 cmReference
Height340 cmReference
Ground clearance40 cmReference
Electrical
GroundnegativeReference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
