Tractor · 2014Unverified

Massey Ferguson 8737

Name: Massey Ferguson 8737
Brand: Massey Ferguson

Massey Ferguson 8737 — Row-Crop tractor · 305 hp. Reference specifications; pending source verification.

The Massey Ferguson 8737 tractor model is rated at approximately 305 hp, positioning it within the more powerful segment of its class. This model was in production from 2014 to 2017. It features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a continuously variable transmission. The operating weight of the 8737 is listed as 10800 kg, making it suitable for operations of 1,500 acres and above.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

305 hp

Max power

243.4 kW

Weight

10800 kg

Catalogue coverage

Variants represented

Richest spec table

68 rows

Recorded power

305 hp

Recorded weight

10800 kg

Transmissions

continuously variable transmission (CVT)

Production years

2014-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Row-Crop tractorReference

Built in Jackson, Minnesota, USAReference

Four-wheel driveReference

Differential lockelectro-hydraulicReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning. Optional OptiRide Plus hydraulic cab suspension. AgCommand ready; AUTO-GUIDE 3000Reference

Variants

MT685Esimilar Challenger modelReference

Engine

AGCO POWER 8.4L 6-cyl dieselReference

Fuel tank628.3 LReference

Exhaust fluid (DEF)59.8 LReference

Engine253.5 kWReference

Drawbar (tested)201.2 kWReference

AGCO POWERReference

turbocharged with air-to-air intercooler dieselReference

6-cylinder 24-valveReference

liquid-cooledReference

Displacement8.4 LReference

Bore/Stroke111 x 145 mmReference

EmissionsTier IVReference

Emission controlselective catalytic reduction (SCR)Reference

Power253.5 kWReference

Maximum Power275.9 kWReference

Rated RPM2100Reference

StarterelectricReference

Starter volts12Reference

Max power243.4 kWReference

Power at rated engine speed227.3 kWReference

Max power201.2 kWReference

Transmission

continuously variable transmission (CVT)Reference

TransmissionDyna-VTReference

Typecontinuously variable transmission (CVT)Reference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)216.3 kWReference

PTO (tested)243.4 kWReference

Typeclosed center load sensing (CCLS)Reference

Pressure200.0 barReference

Valves4 to 6Reference

Pump flow204.4 lpmReference

Rear TypeIII/IVNReference

Rear lift (at ends)11999 kgReference

DrawbarCat. 3Reference

DrawbarCat 3 Heavy Duty (optional)Reference

DrawbarCat 4 (optional)Reference

Rear PTOindependentReference

Rear PTO Type1000/1000E (1.75)Reference

Power at rated PTO speed234.7 kWReference

Dimensions

Wheelbase309 cmReference

Weight10800 kgReference

Length555 cmReference

Height (cab)358 cmReference

Shipping weight10800 kgReference

Bar rear axle109 by 2667 mmReference

Bar rear axle109 by 2997 mmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps240 (twin 120A)Reference

Charging volts12Reference

Battery volts12Reference

Test results

Diesel Dyna-VT 4WDJanuary 2015 - April 2015, Link: OCED Tractor Test 2910 fileReference

PTO performanceReference

Fuel use66.2 l/hourReference

Fuel use65.9 l/hourReference

Drawbar performanceReference

Pull at 10.39KPHReference

Max pull9922 kgReference

Pull at 2.55KPHReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
