Tractor · 2000Unverified
McCormick Intl CX50
McCormick Intl CX50 — CX Series · 53 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
53 hp
Weight
7132 to 7815 pounds
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Utility tractorReference
Built in Doncaster, EnglandReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard.Reference
Engine
Perkins 2.7L 3-cyl dieselReference
Fuel tank155.2 LReference
Engine39.5 kWReference
PerkinsReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power39.5 kWReference
Rated RPM2250Reference
Torque177.0 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synch shuttleReference
16-speed two-speed power shiftReference
Typesynch shuttleReference
Gears8 forward and reverseReference
Clutch304mm dry discReference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Typeopen centerReference
SCV flow53.0 lpmReference
Rear TypeIIReference
Rear lift2039 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1954Reference
Dimensions
2WD Wheelbase215 cmReference
4WD Wheelbase221 cmReference
Weight7132 to 7815 poundsReference
Front tire6.00-16Reference
2WD Rear tire12.4R32Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 12.4R32Reference
4WD Standard tires (ag)Front: 8.3R24. Rear: 12.4R32Reference
Length406 cmReference
Width196 cmReference
Width214 cmReference
2WD Weight3235 kgReference
4WD Weight3544 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
