Tractor · 2006Unverified
McCormick Intl MB55
McCormick Intl MB55 — MB Series · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
2424 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick IntlReference
Utility tractorReference
Two-wheel driveReference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
Four-post ROPS. Optional canopy.Reference
Engine
Perkins 3.3L 3-cyl dieselReference
Fuel tank87.1 LReference
Engine43.3 kWReference
Perkins 1103C-33Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke105 x 127 mmReference
Power43.3 kWReference
Compression19.25:1Reference
Rated RPM2200Reference
Torque221.7 NmReference
Torque RPM1400Reference
Transmission
12-speedReference
24-speedReference
Gears12 forward and reverseReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)40.3 kWReference
Pressure179.3 barReference
Valves1 or 2Reference
Pump flow52.2 lpmReference
Total flow72.7 lpmReference
Rear TypeIIReference
Rear lift2585 kgReference
Rear lift3692 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase212 cmReference
Weight2424 kgReference
Front tire7.50-16Reference
Rear tire14.9R28Reference
Ag front7.50-16Reference
Ag rear14.9R28Reference
Length323 cmReference
Width167 cmReference
Height (steering wheel)169 cmReference
Height (ROPS)241 cmReference
Ground clearance35 cmReference
Front tread132 to 181 cmReference
Rear tread130 to 189 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
