Tractor · 2014Unverified
McCormick Intl X50.30m
McCormick Intl X50.30m — X50 Series · 82 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
82 hp
Weight
3323 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockelectro-hydraulicReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulic (optional)Reference
Variants
X50.30mutilityReference
X50.20m HChigh-cropReference
Engine
Perkins 3.4L 4-cyl dieselReference
Fuel tank102.2 LReference
Perkins 854E-E34TAReference
turbocharged aftercooled dieselReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
EmissionsInterim Tier 4Reference
Emission controlexhaust gas recirculation (EGR)Reference
Maximum Power70.8 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2200Reference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
24-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)60.8 kWReference
Valves2Reference
Pump flow52.2 lpmReference
Total flow81.8 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2585 kgReference
Rear lift3692 kgReference
Rear PTOindependentReference
Rear PTO Type540/750 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
2WD Wheelbase233 cmReference
4WD Wheelbase231 cmReference
Weight3323 kgReference
Front tire12.4-24Reference
Rear tire18.4-30Reference
Standard tires (ag)Front: 12.4-24. Rear: 18.4-30Reference
Length413 cmReference
Width206 cmReference
Height (ROPS)254 cmReference
Height (cab)248 cmReference
Ground clearance40 cmReference
Front tread154 to 195 cmReference
Rear tread160 to 200 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
