Tractor · 2012Unverified
McCormick Intl X50.50
McCormick Intl X50.50 — X50 Series · 98 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
98 hp
Weight
8030 to 8470 pounds
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Utility tractorReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS. Cab available with air-conditioning.Reference
Engine
Perkins 3.4L 4-cyl dieselReference
Fuel tank102.2 LReference
Perkins 854E-E34TAReference
turbocharged aftercooled dieselReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
EmissionsInterim Tier 4Reference
Emission controlexhaust gas recirculation (EGR)Reference
Maximum Power84.3 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2200Reference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
12-speed power shutteReference
32-speed three-speed power shift with power shuttleReference
TransmissionSpeed FourReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutch330mm dry discReference
Typepower shutteReference
Clutchwet discsReference
TransmissionXtraspeedReference
Typethree-speed power shift with power shuttleReference
Gears32 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)72.7 kWReference
Valves2 to 4Reference
Pump flow52.2 lpmReference
Total flow81.8 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift4740 kgReference
Front HitchoptionalReference
Front lift1796 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discsReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Rear PTO Type540/750/1000Reference
Front PTOindependent (optional)Reference
Dimensions
2WD Wheelbase236 cmReference
4WD Wheelbase233 cmReference
Weight8030 to 8470 poundsReference
Front tire380/70R24Reference
Rear tire480/70R34Reference
Standard tires (ag)Front: 380/70R24. Rear: 480/70R34Reference
Length416 cmReference
Width210 cmReference
Height (ROPS)255 cmReference
Height (cab)256 cmReference
Weight3642 kgReference
Weight3841 kgReference
Ground clearance46 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
