Tractor · 1984Unverified
Mitsubishi MT300
Mitsubishi MT300 · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
2337 to 2558 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Two- or four-wheel driveReference
Differential lockrear standardReference
SteeringmanualReference
SteeringpowerReference
Wet disc brakesReference
Open operator station.Reference
Variants
MT3002WDReference
MT300D4WDReference
Engine
Mitsubishi 1.5L 3-cyl dieselReference
Engine22.4 kWReference
Mitsubishi K3MReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 90 mmReference
Power22.4 kWReference
Air cleanerdry elementReference
Rated RPM2700Reference
Starter volts12Reference
Transmission
9-speed synchromeshReference
hydrostaticReference
TypesynchromeshReference
Gears9 forward and 3 reverseReference
Clutchdry discReference
Three gears (1-3) plus reverse (R) in three ranges (low/medium/high). Optional creeper range.Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)19.4 kWReference
Typeopen centerReference
Pump flow21.6 lpmReference
Steering flow7.2 lpmReference
Rear TypeIReference
Controlposition controlReference
Controldraft controlReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2307Reference
Engine RPM1000@2353Reference
Dimensions
Wheelbase157 cmReference
Weight2337 to 2558 poundsReference
Front tire5.00-15Reference
2WD Rear tire12.4-24Reference
2WD Standard tires (ag)Front: 5.00-15. Rear: 12.4-24Reference
4WD Standard tires (ag)Front: 7-16. Rear: 12.4-24Reference
2WD Lawn/turf front20x8.00-10Reference
4WD Lawn/turf front6-14Reference
Lawn/turf rear13.6-16Reference
Length293 cmReference
Width140 cmReference
4WD Height141 cmReference
2WD Height142 cmReference
2WD Weight1060 kgReference
4WD Weight1160 kgReference
4WD Ground clearance27 cmReference
2WD Ground clearance34 cmReference
2WD Front tread107 to 133 cmReference
4WD Front tread119 cmReference
Rear tread101 to 152 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
