Tractor · 1968Unverified

Oliver 2050

Name: Oliver 2050
Brand: Oliver

Oliver 2050 — 50 Series · 119 hp. Reference specifications; pending source verification.

The Oliver 2050 is a tractor model with a rated output of 119 hp, situating it in the middle of its class in terms of power. It was manufactured between 1968 and 1969. The tractor is powered by a 6-cylinder diesel liquid-cooled engine, which transmits power through a four-wheel drive system with a powershift transmission. Its listed weight is 6595 kg, and it is designed for use on plots of around 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

119 hp

Max power

71.9 kW

Weight

6595 kg

Catalogue coverage

Variants represented

Richest spec table

80 rows

Recorded power

119 hp

Recorded weight

6595 kg

Transmissions

6-speed unsynchronized gear

Production years

1968-1969

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerOliverReference

Row-Crop tractorReference

Built in Charles City, Iowa, USAReference

Total built383Reference

Original price was $12,000 in 1969Reference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Power steeringReference

Independent disc brakesReference

Open operator station. Cab optional with air-conditioning.Reference

Engine

Oliver-Hercules 7.8L 6-cyl dieselReference

Fuel tank104.1 LReference

Fuel tank295.2 LReference

Drawbar (tested)71.9 kWReference

Oliver-HerculesReference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement7.8 LReference

Bore/Stroke116 x 124 mmReference

Air cleanerdryReference

Compression18.0:1Reference

Rated RPM2400Reference

Firing order1-5-3-6-2-4Reference

Starter volts12Reference

Oil capacity18.0 LReference

Coolant capacity26.5 LReference

Power at rated engine speed88.6 kWReference

Max power71.9 kWReference

Transmission

6-speed unsynchronized gearReference

18-speed partial powershiftReference

Typeunsynchronized gearReference

Gears6 forward and 2 reverseReference

Clutch330mm cerametallic discReference

TransmissionHydraul-ShiftReference

Typepartial powershiftReference

Gears18 forward and 6 reverseReference

Oliver Hydraul-Shift provides a clutchless, on-the-move shift to an over- and under-drive for each of six forward gears.Reference

PTO & Hydraulics

PTO (claimed)88.0 kWReference

PTO (tested)88.6 kWReference

Typeopen centerReference

Pressure141.3 barReference

Valves2 to 4Reference

Pump flow34.1 lpmReference

Rear TypeIIIReference

Controlposition and draft controlReference

Rear lift (at 24"/610mm)2721 kgReference

Rear PTOindependentReference

Rear PTO Type1000Reference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase248 cmReference

Weight6595 kgReference

Front tire11.00-16Reference

Rear tire18.4-38Reference

Ag front11.00-16Reference

Ag rear18.4-38Reference

Ag rear23.1-34Reference

Ag rear24.5-32Reference

Length412 cmReference

Height (steering wheel)217 cmReference

Operating weight6595 kgReference

Ballasted weight8568 kgReference

Ground clearance48 cmReference

2WD Front tread152 to 203 cmReference

4WD Front tread167/179/203 cmReference

2WD Rear tread154 to 231 cmReference

4WD Rear tread156 to 283 cmReference

2050 Serial Numbers

1968204444Reference

1969212560Reference

Final213932Reference

FAQ: How to read a serial number table.Reference

Test results

Diesel 18-speed 2WDSeptember 23 - October 7, 1968Link: Nebraska Tractor Test 987 fileReference

PTO performanceReference

Fuel use28.4 l/hourReference

Drawbar performanceReference

Fuel use28.8 l/hourReference

Gear 4-under used for power test.Reference

Max pull5997 kgReference

Gear 1-over used for pull test.Reference

Speeds

With 18.4-38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
