Tractor · 1920Unverified
Toro 6-10
Toro 6-10 — Standard-tread tractor · 6 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
6 hp
Max power
7.4 kW
Weight
1043 kg
Hover a source tag to verify
Overview
ManufacturerToroReference
Standard-tread tractorReference
Built in Minneapolis, Minnesota, USAReference
Original price was $850 in 1925Reference
The Toro model 6-10 was also sold as the Toro Tractor 10 and the Toro Tractor 12.Reference
Two-wheel driveReference
Final drivesspur gearReference
Manual steeringReference
Open operator station.Reference
Engine
LeRoi 2.3L 4-cyl gasolineReference
Fuel tank41.6 LReference
Drawbar (claimed)4.5 kWReference
Belt (claimed)7.5 kWReference
Plows1 (14-inch)Reference
Drawbar (tested)7.4 kWReference
Belt (tested)9.9 kWReference
LeRoiReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke79 x 114 mmReference
Rated RPM1200Reference
Coolant capacity13.2 LReference
Belt power (max)9.9 kWReference
Max power7.4 kWReference
Transmission
2-speed sliding gearReference
Typesliding gearReference
Gears2 forward and 1 reverseReference
Clutchcontracting bandReference
Dimensions
Weight1043 kgReference
Front tire26x4Reference
Rear tire42x6Reference
Ag front26x4 (steel)Reference
Ag rear42x6 (steel)Reference
Length266 cmReference
Width106 cmReference
Height129 cmReference
Ground clearance26 cmReference
Rear tread81 cmReference
Test results
Gasoline 2WDSeptember 231920, - September 29, 1920Link: Nebraska Tractor Test 65 fileReference
Belt fuel use (max)6.4 l/hourReference
Drawbar performanceReference
Max pull594 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
