Tractor · 1991Unverified
AGCO Allis 8630
AGCO Allis 8630 — Row-Crop tractor · 120 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
120 hp
Max power
69.8 kW
Weight
4762 kg
Hover a source tag to verify
Overview
DistributorAGCO AllisReference
ManufacturerSAMEReference
Row-Crop tractorReference
Built in ItalyReference
Original price was $65,500 in 1997Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
Antares 130similar SAME modelReference
Engine
SLH 6.0L 6-cyl dieselReference
Fuel tank210.1 LReference
Drawbar (tested)69.8 kWReference
SLH 1000.6 ATReference
turbocharged dieselReference
6-cylinderReference
air-cooledReference
Displacement6.0 LReference
Bore/Stroke105 x 116 mmReference
Rated RPM2500Reference
Starter volts12Reference
Power at rated engine speed89.2 kWReference
Max power69.8 kWReference
Transmission
24-speed partially synchronizedReference
36-speed partial power shiftReference
Typepartially synchronizedReference
Gears24 forward and 12 reverseReference
Six synchronized gears in four ranges with synchronized reverser.Reference
Typepartial power shiftReference
Gears36 forward and reverseReference
PTO & Hydraulics
PTO (claimed)88.7 kWReference
PTO (tested)89.2 kWReference
Typeopen centerReference
Valves3Reference
Pump flow104.8 lpmReference
Rear TypeIII/IIReference
Rear lift4540 kgReference
Rear PTOindependentReference
Rear PTO Type540/540E/1000/1000EReference
Dimensions
Wheelbase279 cmReference
Weight4762 kgReference
Front tire11.00-16Reference
Rear tire18.4R38Reference
Ag front11.00-16Reference
Ag rear18.4R38Reference
8630 Serial Numbers
Location:Console, right sideReference
19911001Reference
19921157Reference
19931251Reference
19941444Reference
19951501Reference
19961509Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 48-speed 4WDNovember 1990 - 1990, Link: OCED Tractor Test 1306 fileReference
PTO performanceReference
Fuel use26.5 l/hourReference
Drawbar performanceReference
Fuel use26.9 l/hourReference
Gear 6N-Lo used for power test.Reference
Max pull5066 kgReference
Gear 4N-Hi used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
