Backhoe Loader · 1982Unverified

Allis Chalmers 714C

Name: Allis Chalmers 714C
Brand: Allis Chalmers

Allis Chalmers 714C — 700C Series · 65 hp. Reference specifications; pending source verification.

The Allis Chalmers 714C is a backhoe loader with a rated output of 65 hp, placing it in the middle of its class for power. Manufactured from 1982 to 1984, this model features a 4-cylinder turbocharged diesel liquid-cooled engine, which powers a two-wheel drive system via a 4-speed gearbox. It is designed for use on jobs of approximately 200 acres. Specifications for this model are provided in both imperial and US units.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

65 hp

Catalogue coverage

Variants represented

Richest spec table

71 rows

Recorded power

65 hp

Transmissions

4-speed torque converter

Production years

1982-1984

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAllis ChalmersReference

Backhoe loader tractorReference

Two-wheel driveReference

Final drivesinboard planetaryReference

Power steeringReference

Mechanical wet disc brakesReference

Four-post ROPS/FOPS.Reference

Engine

Allis-Chalmers 3.3L 4-cyl dieselReference

Engine48.5 kWReference

Allis-Chalmers 433TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement3.3 LReference

Bore/Stroke98 x 108 mmReference

Power48.5 kWReference

Fuel systemdirect injectionReference

Compression14.1:1Reference

Rated RPM2300Reference

Idle RPM775-2580Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Coolant capacity15.1 LReference

Oil capacity11.4 LReference

Oil change100 hReference

Transmission

4-speed torque converterReference

TransmissionWarnerReference

Typetorque converterReference

Gears4 forward and reverseReference

Capacities

Fuel75.7 LReference

PTO & Hydraulics

Hydraulic system102.2 LReference

Typeopen centerReference

Capacity102.2 LReference

Total flow109.8 lpmReference

Steering flow18.9 lpmReference

Steering press.103.4 barReference

Dimensions

Wheelbase213 cmReference

Front tire11L-16Reference

Rear tire16.9-24Reference

Industrial front11L-16Reference

Industrial rear16.9-24Reference

Length716 cmReference

Width210 cmReference

Height (ROPS)251 cmReference

Height (backhoe)345 cmReference

Ground clearance33 cmReference

Front tread170 cmReference

Rear tread165 cmReference

Backhoe & Loader

Dig depth431 cmReference

Dump angle114 cmReference

714C Serial Numbers

Location:Serial number plate on the left side of the frame, just behind the engine bay.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps42Reference

Charging amps61Reference

Batteries1Reference

Batteries2Reference

Battery CCA95Reference

Battery volts12Reference

Battery Group30HReference

Attachment overview

Front-end loaderReference

BackhoeReference

Allis Chalmers 714C Backhoe

Backhoe typeAllis Chalmers 714C BackhoeReference

Transport height345 cmReference

Digging depth431 cmReference

Reach from pivot535 cmReference

Loading height312 cmReference

Swing Arc180°Reference

Bucket force4581 kgReference

Dipperstick force3193 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
