Allis Chalmers FD3
Allis Chalmers FD3 · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1428 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Built in FranceReference
Two-wheel driveReference
Open operator station.Reference
Engine
Vendeuvre 1.6L 2-cyl dieselReference
Perkins 1.6L 4-cyl dieselReference
Fuel tank45.0 LReference
Engine18.6 kWReference
Vendeuvre Type 52Reference
dieselReference
2-cylinderReference
air-cooledReference
Displacement1.6 LReference
Bore/Stroke100 x 100 mmReference
Power18.6 kWReference
Rated RPM2200Reference
Oil capacity7.0 LReference
Perkins 4.99Reference
4-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke79 x 89 mmReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear PTO Type540/1000Reference
Mid PTO Type1000Reference
Dimensions
Weight1428 kgReference
Front tire450x16Reference
Rear tire10x28Reference
Ag front450x16Reference
Ag rear10x28Reference
Length284 cmReference
Height (steering wheel)130 cmReference
Front tread113 to 153 cmReference
Rear tread128 to 167 cmReference
FD3 Serial Number Location
Left-center on tractor frame.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
