Tractor · 2002Unverified
CaseIH MXM130 Maxxum
CaseIH MXM130 Maxxum — Maxxum Series · 113 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
113 hp
Weight
5404 kg
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Row-Crop tractorReference
Built in Basildon, EnglandReference
Two- or four-wheel driveReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
CNH 7.5L 6-cyl dieselReference
Engine96.2 kWReference
CNHReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement7.5 LReference
Bore/Stroke112 x 127 mmReference
Power96.2 kWReference
Air cleanerdual paper elementsReference
Compression17.0:1Reference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity18.9 LReference
Coolant capacity25.4 LReference
Power at rated engine speed84.5 kWReference
Transmission
18-speed partial powershiftReference
Typepartial powershiftReference
Gears18 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)78.3 kWReference
PTO (tested)84.5 kWReference
Hydraulic system89.9 LReference
Typeclosed-center load sensingReference
Capacity89.9 LReference
Pressure189.6 barReference
Valves2 to 5Reference
Pump flow106.0 lpmReference
SCV flow94.6 lpmReference
Total flow166.5 lpmReference
Steering flow60.6 lpmReference
Rear TypeIIReference
Controlelectronic lower-link sensingReference
Rear lift (at 24"/610mm)3957 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed84.1 kWReference
Capacities
Fuel283.9 LReference
Dimensions
Wheelbase274 cmReference
4WD Wheelbase272 cmReference
Weight5404 kgReference
2WD Length458 cmReference
4WD Length471 cmReference
Height (cab)282 cmReference
Height (cab)295 cmReference
4WD Operating weight5404 kgReference
Flange rear axleReference
Bar rear axle91 by 2489 mmReference
4WD Front tread152 to 223 cmReference
Rear tread152 to 223 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery CCA1300Reference
Battery volts12Reference
Battery AH176Reference
Test results
Diesel 18-speed 4WDDecember 1, 2002 - March 1, 2003Link: OCED Tractor Test 2088 fileReference
PTO performanceReference
Fuel use27.3 l/hourReference
Fuel use26.5 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
