Tractor · 2003Unverified
Challenger MT255
Challenger MT255 — MT200 Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1019 kg
Hover a source tag to verify
Overview
DistributorChallenger (a part of AGCO)Reference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS.Reference
Variants
1429similar Massey Ferguson modelReference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank22.7 LReference
Engine (gross)21.2 kWReference
IsekiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke86 x 84 mmReference
Power (gross)21.2 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed constant meshReference
Typeconstant meshReference
Gears9 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)18.0 kWReference
Typeopen centerReference
Pressure146.9 barReference
Pump flow28.0 lpmReference
Total flow37.5 lpmReference
Steering flow9.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Controldraft controlReference
Rear lift (at ends)899 kgReference
Rear lift (at 24"/610mm)600 kgReference
Rear PTOliveReference
Clutchdry discReference
Rear PTO Type540 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase163 cmReference
Weight1019 kgReference
Front tire6-14Reference
Rear tire12.4-16Reference
Standard tires (ag)Front: 6-14. Rear: 12.4-16Reference
Lawn/turf front24x8.50-12Reference
Lawn/turf rear315/80D-16Reference
Industrial front25x8.50-14Reference
Industrial rear12.5/80-18Reference
Length295 cmReference
Width129 cmReference
Height (ROPS)201 cmReference
Front tread106 cmReference
Rear tread94 to 94 cmReference
Challenger MT255 attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
