Tractor · 2003Unverified

Challenger MT255

Name: Challenger MT255
Brand: Challenger

Challenger MT255 — MT200 Series · 28 hp. Reference specifications; pending source verification.

The Challenger MT255 is a tractor model rated at 28 hp, representing one of the more compact options in its class. It was manufactured between 2003 and 2005. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, which powers a 4-wheel drive system through a 9-speed gearbox. The listed weight for the Challenger MT255 is 1019 kg, with an application for jobs of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Weight

1019 kg

Catalogue coverage

Variants represented

Richest spec table

69 rows

Recorded power

28 hp

Recorded weight

1019 kg

Transmissions

9-speed constant mesh

Production years

2003-2005

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorChallenger (a part of AGCO)Reference

ManufacturerIsekiReference

Compact Utility tractorReference

Built in Matsuyama, JapanReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post fixed ROPS.Reference

Variants

1429similar Massey Ferguson modelReference

Engine

Iseki 1.5L 3-cyl dieselReference

Fuel tank22.7 LReference

Engine (gross)21.2 kWReference

IsekiReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke86 x 84 mmReference

Power (gross)21.2 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

9-speed constant meshReference

Typeconstant meshReference

Gears9 forward and 3 reverseReference

PTO & Hydraulics

PTO (claimed)18.0 kWReference

Typeopen centerReference

Pressure146.9 barReference

Pump flow28.0 lpmReference

Total flow37.5 lpmReference

Steering flow9.5 lpmReference

Rear TypeIReference

Controlposition controlReference

Controldraft controlReference

Rear lift (at ends)899 kgReference

Rear lift (at 24"/610mm)600 kgReference

Rear PTOliveReference

Clutchdry discReference

Rear PTO Type540 (1.375)Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase163 cmReference

Weight1019 kgReference

Front tire6-14Reference

Rear tire12.4-16Reference

Standard tires (ag)Front: 6-14. Rear: 12.4-16Reference

Lawn/turf front24x8.50-12Reference

Lawn/turf rear315/80D-16Reference

Industrial front25x8.50-14Reference

Industrial rear12.5/80-18Reference

Length295 cmReference

Width129 cmReference

Height (ROPS)201 cmReference

Front tread106 cmReference

Rear tread94 to 94 cmReference

Challenger MT255 attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
