Tractor · 1969Unverified
Leyland 384
Leyland 384 · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
2540 kg
Hover a source tag to verify
Overview
ManufacturerLeylandReference
Two-wheel driveReference
Final drivesspur gearReference
Manual steeringReference
Mechanical dry disc brakesReference
Open operator station. Cab optional.Reference
Engine
Leyland 3.8L 4-cyl dieselReference
Engine (gross)55.9 kWReference
Leyland 38 TDReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power (gross)55.9 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression17.3:1Reference
Rated RPM2200Reference
Torque238.7 NmReference
Torque RPM1400Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Oil capacity7.6 LReference
Coolant capacity13.6 LReference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
Clutch279mm dry discReference
Oil capacity56.8 LReference
PTO & Hydraulics
PTO (claimed)41.8 kWReference
PTO (claimed)46.2 kWReference
Hydraulic system56.4 LReference
Typeopen centerReference
Capacity56.4 LReference
Pump flow29.5 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift2233 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1813Reference
Capacities
Fuel68.1 LReference
Dimensions
Wheelbase203 cmReference
Weight2540 kgReference
Front tire7.50-16Reference
Rear tire13.6/12-36Reference
Ag front7.50-16Reference
Ag rear13.6/12-36Reference
Ag rear16.9/14-30Reference
Ag rear18.4/15-30Reference
Ag rear13.6-12-38Reference
Length340 cmReference
Width174 cmReference
Height (steering wheel)167 cmReference
Height (exhaust)223 cmReference
Clearance (front axle)46 cmReference
Clearance (rear axle)61 cmReference
Front tread132 to 193 cmReference
Rear tread132 to 203 cmReference
Electrical
Charging systemgeneratorReference
Charging amps18Reference
Battery volts12Reference
Battery AH120Reference
Speeds
With 13.6/12-36 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
