The Massey Ferguson 254S is a compact tractor with a rated output of 56 hp, produced between 1983 and 1987. It features a 3-cylinder turbocharged diesel liquid-cooled engine and mechanical front-wheel drive with a hydrostatic transmission. The tractor weighs between 4674 and 5226 pounds, and is suitable for jobs requiring up to 200 acres of coverage.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
56 hp
Weight
4674 to 5226 pounds
Catalogue coverage
Variants represented
2
Richest spec table
35 rows
Recorded power
56 hp
Recorded weight
2120 kg
Transmissions
12-speed
Production years
1983-1987
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerLandiniReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank62.1 LReference
Engine41.8 kWReference
Perkins AD3.152Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power41.8 kWReference
Rated RPM2200Reference
Torque178.0 NmReference
Torque RPM1200Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Total flow36.0 lpmReference
Rear lift2400 kgReference
Rear PTO Type540/1000/groundReference
Dimensions
Wheelbase205 cmReference
Weight4674 to 5226 poundsReference
Front tire7.50-16Reference
Rear tire12.4-32Reference
Ag front7.50-16Reference
Ag rear12.4-32Reference
Ag front11.2-20Reference
Length366 cmReference
Height240 cmReference
Weight2120 kgReference
Weight2370 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
