Industrial Tractor · 1982Unverified
Allis Chalmers 710C
Allis Chalmers 710C — 700C Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Industrial tractorReference
Two-wheel driveReference
Final drivesinboard planetaryReference
Power steeringReference
Mechanical wet disc brakesReference
Four-post ROPS/FOPS.Reference
Engine
Allis-Chalmers 3.3L 4-cyl dieselReference
Engine48.5 kWReference
Allis-Chalmers 433TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement3.3 LReference
Bore/Stroke98 x 108 mmReference
Power48.5 kWReference
Fuel systemdirect injectionReference
Compression14.1:1Reference
Rated RPM2300Reference
Idle RPM775-2580Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity15.1 LReference
Oil capacity11.4 LReference
Oil change100 hReference
Transmission
4-speed torque converterReference
TransmissionWarnerReference
Typetorque converterReference
Gears4 forward and reverseReference
PTO & Hydraulics
PTO (claimed)18.6 kWReference
Hydraulic system102.2 LReference
Typeopen centerReference
Capacity102.2 LReference
Rear valves2Reference
Pump flow68.1 lpmReference
Pump flow41.6 lpmReference
Total flow109.8 lpmReference
Steering flow18.9 lpmReference
Steering press.103.4 barReference
Rear TypeIIReference
Rear PTOindependentReference
ClutchhydraulicReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2100Reference
Capacities
Fuel75.7 LReference
Dimensions
Wheelbase213 cmReference
Front tire11L-16Reference
Rear tire16.9-24Reference
Industrial front11L-16Reference
Industrial rear16.9-24Reference
Width210 cmReference
Height (ROPS)251 cmReference
Ground clearance33 cmReference
Front tread170 cmReference
Rear tread165 cmReference
Allis Chalmers 710C attachments
front-end loaderReference
710C Serial Numbers
Location:Serial number plate on the left side of the 710C, just behind the engine.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps42Reference
Charging amps61Reference
Batteries1Reference
Batteries2Reference
Battery CCA95Reference
Battery volts12Reference
Battery Group30HReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
