Tractor · 2007Unverified
CaseIH JX70
CaseIH JX70 — JX Series · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
5152 to 6365 pounds
Hover a source tag to verify
Overview
DistributorCaseIHReference
ManufacturerTurk TractorReference
Utility tractorReference
Built in Ankara, TurkeyReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydrostatic powerReference
Brakeshydraulic wet disc (USA)Reference
Brakesmechanical wet discReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Iveco 2.9L 3-cyl dieselReference
Fuel tank90.1 LReference
Engine (gross)46.2 kWReference
IvecoReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Power (gross)46.2 kWReference
Fuel systemdirect injection with mechanical governorReference
Air cleanerdual dry elementsReference
Rated RPM2500Reference
Torque250.0 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
20-speed mechanical shuttle with creeperReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Three ranges with four gears per range. Left-hand reverser requires use of clutch to change directionsReference
Typemechanical shuttle with creeperReference
Gears20 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)38.8 kWReference
Typeopen centerReference
Pressure190.0 barReference
Valves1 to 3, 1 mid optionalReference
Pump flow40.1 lpmReference
Pump flow51.5 lpmReference
Total flow82.1 lpmReference
Steering flow30.7 lpmReference
Rear TypeII/IReference
Controlmechanical draft sensingReference
Rear lift (at 24"/610mm)1818 kgReference
Rear PTOindependentReference
Clutchmechanical dry discReference
Rear PTO Type540Reference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase218 cmReference
Wheelbase213 cmReference
Weight5152 to 6365 poundsReference
Length391 cmReference
Length386 cmReference
Width180 cmReference
Height (ROPS)246 cmReference
Height (cab)254 cmReference
Shipping2336 kgReference
Shipping2636 kgReference
Shipping2587 kgReference
Shipping2887 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps85Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
