Tractor · 1984Unverified
Massey Ferguson 699
Massey Ferguson 699 — 600 Series · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Max power
51.7 kW
Weight
8304 to 10325 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in Beauvais, FranceReference
Original price was $35,000 in 1986Reference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS. Cab available with air-conditioning.Reference
Variants
6992WDReference
699-44WDReference
Engine
Perkins 5.8L 6-cyl dieselReference
Fuel tank145.0 LReference
Drawbar (tested)51.7 kWReference
Perkins 6.354.4Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.8 LReference
Bore/Stroke98 x 127 mmReference
Rated RPM2200Reference
Starter volts12Reference
Power at rated engine speed64.0 kWReference
Max power51.7 kWReference
Transmission
12-speed synchromeshReference
TypesynchromeshReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)63.4 kWReference
PTO (tested)64.0 kWReference
Typeopen centerReference
Pressure172.4 barReference
Valves2 or 3Reference
Pump flow37.9 lpmReference
Pump flow26.5 lpmReference
Total flow64.3 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)2385 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@1900Reference
Engine RPM1000@1900Reference
Power at rated PTO speed58.2 kWReference
Dimensions
Wheelbase258 cmReference
Weight8304 to 10325 poundsReference
Front tire10.00-16Reference
2WD Rear tire18.4-34Reference
2WD Standard tires (ag)Front: 10.00-16. Rear: 18.4-34Reference
4WD Standard tires (ag)Front: 14.9-24. Rear: 18.4-34Reference
Length432 cmReference
Width205 cmReference
Height (cab)271 cmReference
Flange rear axleReference
2WD Front tread162 to 195 cmReference
4WD Front tread167 to 187 cmReference
Rear tread152 to 243 cmReference
2WD ROPS Shipping3766 kgReference
2WD Cab Shipping4129 kgReference
4WD ROPS Shipping4207 kgReference
4WD Cab Shipping4570 kgReference
Operating4683 kgReference
Ballasted5867 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Test results
Diesel 12-speed 4WDSeptember 6 - 28, 1984Link: Nebraska Tractor Test 1541 fileReference
PTO performanceReference
Fuel use20.1 l/hourReference
Fuel use17.4 l/hourReference
Drawbar performanceReference
Fuel use19.7 l/hourReference
Gear 7 used for power test.Reference
Max pull3954 kgReference
Gear 2HL used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
